 滤芯知识分享：更换滤芯的方法：1、单桶预过滤装置滤芯的更换：a.关闭进油口球阀，打开上端盖。（铝合金型上端盖需使用平口螺丝刀从侧面缺口处轻轻撬开）；b.拧开排污口堵丝，排净污油；c将滤芯上端的紧固螺母松开，操作者戴防油手套握紧滤芯，垂直向上取下旧滤芯；d.换上新滤芯，垫好上端密封圈（下端有自带密封垫），上紧螺母；f.拧紧排污口堵丝，盖好上端盖（注意垫好密封圈），上好紧固螺栓。2、双桶并联预过滤装置滤芯的更换：a.先关闭需要更换滤芯一侧过滤器的进油阀，数分钟后关闭出油阀，然后拧下端盖螺栓，打开端盖;b.打开排污阀，彻底排净污油，防止更换滤芯时污油进入净油腔;c.将滤芯上端的紧固螺母松开，操作者戴防油手套握紧滤芯，垂直向上取下旧滤芯;c.换上新滤芯，垫好上端密封圈（下端有自带密封垫），上紧螺母;d.关闭排污阀，盖好上端盖（注意垫好密封圈），上好紧固螺栓。E.先打开进油阀，再打开排气阀，待排气阀出油时立即关闭排气阀，然后打开出油阀即可;再以相同的方法对另一侧过滤器进行操作。

免责声明丨 部分内容来源网络！本文仅供交流学习 , 版权归属原作者，部分图片、内容推送时未能及时与原作者取得联系，若来源标注错误或侵犯到您的权益烦请告知，我们将立即删除.

企业介绍

公司供应摊铺机配件，压路机配件，铣刨机配件，摊铺机刮板驱动轴，刮板驱动轴总成，找平仪，找平仪支架以及液压泵和配件。还供应摊铺机易损件，摊铺机平衡梁，搅龙轴，踏板，输料底板，叶片，熨平板，减速机，链轨，履带板，支重轮，刮板大链条，输料链条等。

联系人：梁经理

联系方式：13645201509（微信同号）

QQ：2870202745

QQ邮箱：2870202745@qq.com

网易邮箱：LS13645201509@163.com

WhatsApp:+86  13645201509

Filter knowledge sharing: Method for replacing filter element: 1. Replacement of filter element for single barrel pre filtration device: a. Close the inlet ball valve and open the upper cover. (The aluminum alloy upper end cover needs to be gently pried open from the side notch using a flat screwdriver); b. Unscrew the drain plug and drain the dirty oil completely; Loosen the fastening nut on the upper end of the filter element, and the operator should wear oil resistant gloves to grip the filter element tightly. Then, remove the old filter element vertically upwards; d. Replace the filter element with a new one, place the upper sealing ring (with a built-in sealing gasket at the lower end), and tighten the nut; f. Tighten the drain plug, cover the upper end cap (note to pad the sealing ring), and tighten the fastening bolts. 2. Replacement of filter element for dual barrel parallel pre filtration device: a. First, close the inlet valve of the filter on the side where the filter element needs to be replaced. After a few minutes, close the outlet valve, then unscrew the end cap bolt and open the end cap; b. Open the drain valve and thoroughly drain the dirty oil to prevent it from entering the clean oil chamber when replacing the filter element; c. Loosen the fastening nut on the upper end of the filter element, and the operator should wear oil resistant gloves to grip the filter element tightly. Then, remove the old filter element vertically upwards; c. Replace the filter element with a new one, place the upper sealing ring (with a built-in sealing gasket at the lower end), and tighten the nut; d. Close the drain valve, cover the upper end cap (pay attention to gasket the sealing ring), and tighten the bolts. E. First, open the oil inlet valve, then open the exhaust valve. When the exhaust valve releases oil, immediately close the exhaust valve, and then open the oil outlet valve; Operate the filter on the other side using the same method.

Disclaimer | Some content is sourced from the internet! This article is for communication and learning purposes only. The copyright belongs to the original author. Some images and content were not promptly contacted when pushed. If the source annotation is incorrect or infringes on your rights, please inform us and we will immediately delete it

Company Introduction

The company supplies paver accessories, roller accessories, milling machine accessories, paver scraper drive shaft, scraper drive shaft assembly, leveling instrument, leveling instrument bracket, hydraulic pump and accessories. We also supply vulnerable parts for pavers, including balance beams, agitator shafts, pedals, feeding base plates, blades, ironing plates, reducers, chain rails, track plates, support wheels, scraper chains, and feeding chains.

Contact: Manager Liang

Contact information: 13645201509 (same WeChat account)

QQ：2870202745

QQ email: 2870202745@qq.com

NetEase email: LS13645201509@163.com

WhatsApp:+86  13645201509
